Mini Desktop Vacuum forming machine
Product Description
For single-piece production of small products. Such as product proofing, Halloween masks, birthday gifts, teaching demonstrations High school CNC education.Institute of industry technology education.and so on.
Working process
Clamp sheet -- moved heating box -- heating -- taken heating box -- mould up -- cooling -- mould down -- clips loose -- take finished products
|
Model |
YN-4040A |
YN-5050A |
|
Forming Size (mm) |
400*400*150 |
500*500*150 |
|
Material Thickness (mm) |
0.1-3 |
0.1-3 |
|
Material size |
450*450 |
550*550 |
|
Power Mode |
Manual |
Manual |
|
Vacuum pump |
Included |
Included |
|
Power Supply |
220V |
220V |
|
Power |
3.6KW |
4KW |
|
Machine Size (m) |
1.26*0.67*0.45 |
1.67*0.81*0.63 |
|
Packaging Size |
1.35*0.75*0.68 |
1.77*0.91*0.83 |
|
Weight |
154kg |
200kg |
 |
 |
 |
 |
 |
 |
|
 |
 |
 |
 |
 |
 |
